Dual Compartment Galvanized Steel Air Conditioner Cooling Outdoor Enclosure Floor Mounting Type
1. Dual Compartment Outdoor Cabinet Key Features & Benefits:
-
Innovative range of telecommunications cabinets
-
Cost-effective solutions
-
19 inch and ETSI standard
-
Hybrid design
-
Environmental protection
-
Security locking systems
-
Single or double skin construction
-
EMC shielding
-
IP rated protection
-
Vented, glazed or steel doors with single or multi-point locking systems
-
Range of cable management options and power supply accessories
-
Bay construction (with the use of baying kit)
-
Designed for maximum thermal and space efficiency
-
Hot and cold aisle containment
2. Dual Compartment Outdoor Cabinet Features
2.1 Dimensions: W*D*H 1600*800*2000mm,
2.2 Dustproof, Sunproof and Rainproof.
2.3 Standard 19” Rack Mountable Equipment.
2.4 Layout : 2 compartments (separated left compartment and right compartment), with middle division plate.
2.5 Electrical Grounding bar inside.
2.6 Doors: Lockable, With 2 front doors, and anti-theft 3-point lock with padlock optional.
2.7 Installation mode: installed on a concrete floor.
2.8 Heat Insulation: 20mm PEF heat insulation between inner wall and outer wall.
2.9 Cabling mode: routed in and out from the bottom.
2.10 Including -48VDC illumination lamp.
2.11 Accessories: PDU, Monitor, Light, Alarm Sensors (Based on request),Batteries.
2.12 Temperature Control: AC220V air conditioner or DC48V fans.
2.13 Protection level:IP55.
2.14 Certificates:CE.
3. Dual Compartment Outdoor Cabinet Description
Double Bay Outdoor Enclosure is available in a variety of configurations, and they can be used in several different applications. The Cabinet is an outstanding robust, cost effective, long service life solution for domestic and international projects. Custom widths, lengths and configurations are also available. It can support Equipments, Batteries, Environment Monitor Unit, PDU and etc. Ultimate security is provided by a three-point locking system. This series enclosures offer all the protection needed for outdoor requirements
4. Cabinet Picutres
5. Our Factory Instruction
Factory Size: 3000 Square Meters
No. of Main Production Lines: 5
Contract Manufacturing: OEM Service Offered, Design
Service Offered, Buyer Label offered
Production Experience: 13 Years
6. Leading Time
Usually about 15-20 days. The exact lead time need to be confirmed according to the quantity of order.
